Spandrel Panels
Our spandrel panels are a reliable and adaptable solution for window and curtain wall façades across a broad range of projects.
Spandrel panels offer a combination of high performance and design flexibility, suitable for both new builds and refurbishment projects. The system is tested in accordance with EN13501-1 and can be customised to integrate seamlessly with window systems, pressure plates and toggle-glazed façades.
- Manufactured with A1‑rated insulation
- U‑values from 0.19–1.46 W/m²K, depending on insulation thickness
- Insulation depths from 20mm to 200mm
- Available as flat or stepped spandrel panels
- Available in aluminium, steel, back‑painted glass and porcelain ceramic
- Large format panels available
Our spandrel panels provides a high‑performance solution that balances functionality with refined architectural appeal.
The system is offered in a wide range of finishes, including aluminium, steel, back‑painted glass and porcelain ceramic, giving designers freedom while meeting strict technical standards. Panels can be fully customised to suit different design intents and edge conditions, allowing smooth integration with glazed façade systems.
Manufactured with A1‑rated insulation, our spandrel panels supports fire safety across applications. With insulation depths from 20mm to 200mm, they provide strong thermal performance which are tailored to each project. The system also achieves an A2‑s1, d0 fire classification, combining safety, efficiency and a clean, modern aesthetic.
Product Details
-
Our spandrel panels have been fully tested to EN 13501-1 standards, ensuring compliance with fire performance regulations.
- PPC Aluminium A2-s1, d0
- Painted Steel A2-s1, d0
- Back Painted Glass A2-s1, d0
- Porcelain Ceramic A2-s1, d0
-
The widths of our spandrel panels vary by material. Refer to the table below for maximum widths by type.
- PPC Aluminium 2000 mm
- Anodised Aluminium 2000 mm
- PPC Steel 1250 mm
- Stainless Steel 1500 mm
- Back Painted Glass Bespoke
- Porcelain Ceramic Bespoke
-
Our spandrel panels are designed to deliver exceptional thermal and acoustic performance, tailored to the specific requirements of your project. With a mineral fibre core insulation providing a linear thermal transmission of 0.038 W/mK, the insulation depth can be adjusted from 20 to 200 mm to achieve the desired thermal efficiency.
For acoustic performance, sound reduction can be customised by varying the thickness of the inner and outer skins. Higher dB ratings are achieved by increasing the mass within the panel. Our technical team is available to help select the optimal configuration for both thermal and acoustic efficiency.
In-House Metal Fabrications
Whether it’s a planned package or an urgent site requirement, our in-house fabrication team can manufacture roofing and cladding components to suit your project.
